Uticor

Industrial nodes, computers and PC

Uticor range of industrial nodes, computers and PCs are a rugged breed suitable for harsh industrial environments.

Features include:

  • Available with AMD, Celeron or Pentium processors up to 3.06 GHz
  • System memory expandable to 1 Gb
  • Available with CDRW and DVDRW drives
  • Hard Disk > 40 Gb
  • Connectivity options include: 2 USB, 1 10/100 Ethernet, 1 VGA, 1 LPT1, 1 RS232 and 1 Firewire
  • Also available with 4 RS232 ports
  • 1 or 2 PCI slots
  • Power supply – 90 to 240 VAC, 180 watt
  • Mounting Depth – 105, 165 or 240 mm depending on model


The new IPX industrial node can now be mounted in a control cabinet.

The PC utilises an industrial Mini ITX Mainboard with an AMD 500MHz processor, a celeron processor or a Pentium 4 processor up to 3.06 GHz. The chosen components guarantee the system will be compatible with future upgrades for years to come.

The IPX can be ordered with 2 different housing style:

  1. The IPX 1 has one free PCI slot and housing dimensions of 240 x 275 x 165mm, It is also available with 4 RS 232 ports, in this case the floppy drive is omitted.
  2. The IPX 2 has 2 free PCI slots and housing dimensions of 382 x 222 x 105mm.

Both the IPX 1 and 2 utilise an internal CDROM drive.

In conjunction with our TFT monitors, we offer a powerful system with screen sizes from 10.4" to 19". Because the screen is seperate from the PC, it is a flexible and modular system at an attractive price. Servicing and maintenance are also simplified.
